Available in 12 models with capacity from 5 to 30 m³
● Series 400: 5 m³
● Series 450: 9 – 11 m³
● Series 500: 11 – 13 – 15 – 17 m³
● Series 600: 17 – 20 – 23 m³
● Series 650: 25 m³
● Series 700: 30 m³
SCARICA IL CATALOGO
TECHNICAL CHART
| Model | Capacity m³ |
Length mm |
Width mm |
Height mm |
Unladen weight Kg |
Power kW | Milk-cows to feed |
|---|---|---|---|---|---|---|---|
| 400/50 ME | 5 | 5173 | 1556 | 1913 | 2800 | 15 | 25-40 |
| 450/90 ME | 9 | 5962 | 1744 | 2100 | 4300 | 30 | 45-75 |
| 450/110 ME | 11 | 6412 | 1744 | 2100 | 4400 | 30 | 55-90 |
| 500/110 ME | 11 | 6266 | 1929 | 2186 | 5300 | 37 | 55-90 |
| 500/130 ME | 13 | 6266 | 1960 | 2436 | 5500 | 37 | 65-100 |
| 500/150 ME | 15 | 6866 | 1960 | 2436 | 5900 | 55 | 75-120 |
| 500/170 ME | 17 | 7166 | 1960 | 2436 | 6100 | 55 | 85-140 |
| 600/170 ME | 17 | 6884 | 2161 | 2536 | 7200 | 90 | 85-140 |
| 600/200 ME | 20 | 7484 | 2161 | 2536 | 7800 | 90 | 100-160 |
| 600/230 ME | 23 | 7784 | 2161 | 2536 | 8000 | 90 | 115-180 |
| 650/250 ME | 25 | 8200 | 2450 | 3060 | 11100 | 132 | 125-200 |
| 700/300 ME | 30 | 9250 | 3169 | 3568 | 14000 | 160 | 150-240 |
STANDARD EQUIPMENT
- Stationary version, with electric motor (ME)
- With n° 2 chopping-mixing augers of high strength steel
- Complete with electric motor
- Without electric control board (see fittings)
- Independent hydraulic installation with electro-valves and keyboard with cable for auxiliaries
- Left side chain discharge conveyor 900 x 800 mm (WxL)
- Preparation for the second discharge side
- Frame made from high strength steel
- Turning chopping star-shaped blades
- Dented, demountable, adjustable counter-blades
- Rear door for the loading of integrative products
- Sekotronic L150 weighing system with n° 15 programs and n° 15 components each
- Inspection access ladder with platform
* ONLY FOR THE 700 MODEL 700
- Left chain discharge conveyor 900 x 1000 mm (WxL)
Stationary version, with electric motor and hydrostatic drive by viscous joint (ME/HD)
This application permits the starting-up of the machine at “full load condition” by simply using the control board for the starting in “empty condition” (instead of the one for “full load “condition). In this way you can save on the price a lot, as well as on the energy consumption, because the viscous joint eliminates quite the peaks of absorption during the starting up phase.
PHOTOGALLERY
